• JA-60 “COMFORT” Alarm system Installation manual. • This manual is valid for control panel model JA-60KX, SW versions FM61215 (control panel board) and DY61232 (telephone communicator board). The use of Comlink Windows v. 58 software or higher is required with this control panel, and can be obtained from our home page at WWW.JABLOTRON.CZ.

• Thank you for purchasing a Jablotron alarm system. Its reliable operation depends on proper installation. We recom- mend having this alarm professionally installed. To find a qualified installer, please contact your Jablotron Distributor.

The manufacturer assumes no liability for damages caused by incorrect installation or improper use of this system. • 2.5 Connection of the telephone line (only for models with an optional built in dialer) • Use the provided telephone cable to connect the telephone line to the IN jack inside the control panel (see fig. 4), • Connect any telephone, fax or other phone operated device to the OUT jack, marked with a phone symbol •. • • Open the detector’s cover by pressing the internal pawl – see fig. 7 • Install the detector to the desired location using the two provided screws. • Be sure that the antenna is vertical (pointing up or down) • Attach the magnet, using the provided screws, to the moving part of the door or window, and attach its cover. Attach the bracket with the two provided screws, being sure that the arrow inside the bracket is pointing up.

We recommend to install one screw in the pre-punched hole on the lever of the tampering sensor (see fig. Testing of detectors and controllers The control panel should be in the programming mode for testing – (LED display will show „P“ )(see part 8. How to enter programming mode). If the control panel will not indicate a detector’s triggering during testing, it means that this detector was not enrolled (see note in part 4.1.). • * can be connected to analogue interfaces TBR 21/1998, EG 201 121 V1.13/2000, AS/ACIF S002/2001 (Australia) Hereby, Jablotron Ltd., declares that this JA-60 is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

Original of the conformity assessment can be found at the web page www.jablotron.cz, section Technical support. Wiring of external devices In addition to using wireless items, which are part of the JA-60 system, hard wired devices can be wired to the system. The JA-60 control panel (JA-60K) and the JA-60N detector are both equipped with terminals for wiring. Use of external sensors with the JA-60N The JA-60N detector can be used to wire external sensors which have contacts on their outputs. For example, it can be used to protect multiple doors or windows (see fig. The built in magnetic sensor of the JA-60N can also be disabled (DIP switch number 2 to position ON) and then the JA-60N works only as an interface for exter- nal sensors. • List of control panel programmable parameters Function sequence options factory note 1& 6 scrolling, hold 2 to erase Enrolling of detectors and controllers position, 3 all controllers, 4 to erase all items Exit delay x = 1 to 9 (x 10sec.) 30sec.

Enrollment (teaching) of wireless items enter: 1 As a maximum 16 detectors and 8 controllers (remote controls & keypads) can be enrolled to the control panel. A wire- less siren and an additional JA-6x control panel (subsystem) can be enrolled as well. • Table for split system: where x represents the following functions (non split system): 23x (PgX) 24x (PgY) 0 Chime – triggered during the entrance delay (pre-alarm output) Alarm A Alarm A 1 Fire – triggered by a fire alarm (by a smoke or a gas detector) Alarm B Alarm B 2 Arm –.
